A2200

THRUSTER SUMMARY:
A2200 is a 500-lbf bipropellant hypergolic engine developed by Agile to provide maximum performance on demanding missions, with a specific impulse of more than 318 seconds.

Using an integral pintle sleeve throttling mechanism, the engine is capable of deep throttling, providing a smooth ride and fine control for a variety of missions. The engine can throttle from 50 to 100% thrust in under 650 milliseconds.

The MON3 and M20 propellants are provided to half-inch inlets at pressures between 470 and 530 psia. The A2200 engine design extensively leverages additive manufacturing resulting in an engine that is only 5.9 kilograms. The engine is qualified for 1000 seconds of firing time after delivery and 30 starts.
